Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-19
C.17 CN4440 Bluetooth2 interface connector (20-pin)
Table C-17 Bluetooth2 interface connector (20-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 GND - 2 ZUSBB2-E3P I/O
3 ZUSBB2-E3N I/O 4 WCHCL2-P3P O
5 BTMDL2-P3N I 6 BTRST2-S3N O
7 WCHDA2-P3P O 8 BT2-P3V -
9 (GND) - 10 GND -
C.18 CN4610 USB port 4 connector (8-pin)
Table C-18 USB port 4 connector (8-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 USB0PS-E5V O 2 ZUSBP0-E3N I/O
3 ZUSBP0-E3P I/O 4 GND -
5 USB0PS-E5V O 6 ZUSBP4-E3N I/O
7 ZUSBP4-E3P I/O 8 GND -
1T GND - 2T GND --
C.19 CN4612 USB port 6 connector (8-pin)
Table C-19 USB port 6 connector (4-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 USB1PS-E5V O 2 USB1PS-E5V I/O
3 USB1PS-E5V I/O 4 ZUSBP6-E3N -
5 ZUSBP6-E3P - 6 GND -
7 GND - 8 GND -
