1 Hardware Overview 1.5 Optical Drive (ODD)
1-18 [CONFIDENTIAL] TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
1.5.3 DVD-Super Multi Drive
The DVD Super Multi drive accommodates either 12 cm (4.72-inch) or 8 cm (3.15-inch)
CD-ROM, DVD-ROM, CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW, DVD-
RAM, DVD-R DL and DVD+R DL.
The specifications are listed in Table 1-5.
Table 1-5 DVD Super Multi drive specifications
Specifications Item
MATSUSHITA G8CC0002Y520
Width (mm) 128 (excluding projections)
Height (mm) 12.7 (excluding projections)
Depth (mm) 129.4 (excluding projections)
Outline
dimensions
Mass (g) 190±10
Data transfer speed (Read)
DVD-ROM
CD-ROM
Max. 8x CAV
Max. 24x CAV
Data transfer speed (Write)
CD-R
CD-RW
DVD-R
DVD-RW
DVD-R DL
DVD+R
DVD+R DL
DVD+RW
DVD-RAM
Max. 24x ZCLV
Max. 16x CLV (Ultra speed)
Max. 8x ZCLV
Max. 4x CLV
Max. 2x ZCLV
Max. 8x ZCLV
Max. 2.4x CLV
Max. 4x ZCLV
Max. 5x ZCLV (4.7GB)
ATAPI Burst (MB/s)
PIO Mode
DMA Mode
Ultra DMA Mode
16.6 (PIO MODE4)
16.6 (Multi Word Mode2)
33.3 (Ultra DMA Mode2)
Data Buffer Capacity 2MB
Access time (ms)
CD-ROM
DVD-ROM
150msec typ.
180msec typ.
Supported Disks CD: CD-ROM (12cm, 8cm), CD-R, CD-RW
DVD: DVD-ROM, DVD-R, DVD-RW, DVD-RAM, DVD+RW
Supported Formats CD: CD-DA, CD-ROM, CD-ROM XA, PHOTO CD,
CD-Extra(CD+), CD-text
DVD: DVD-R, DVD-RW (Ver. 1.1, 1.2), DVD-Video, DVD+R,
DVD+RW, DVD-RAM (2.6GB/4.7GB)

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
