Toshiba TECRA A9 Series Maintenance Manual

4.14 Touch pad 4 Replacement Procedures
4.14 Touch pad
Removing the Touch pad
To remove the touch pad, follow the steps below and refer to Figure 4-23 and 4-24.
1. Lift the tip portions up first and remove the touch pad cover while releasing latches.
2. Remove the following screw and touch pad assembly from the slot.
• M2.5×10B FLAT HEAD screw ×1
Touch pad cover
Touch pad assembly
Tip portion
M2.5×10B FLAT HEAD
Figure 4-23 Removing the touch pad (1)
TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633) [CONFIDENTIAL] 4-39

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
