Toshiba TECRA A9 Series Maintenance Manual

4 Replacement Procedures 4.7 Keyboard
4-22 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)
Installing the Keyboard
To install the keyboard, follow the steps below and refer to Figure 4-9 to 4-11.
1. Place the keyboard face down on the palm rest.
2. Connect the keyboard cable to the connector CN3230 on the system board.
CAUTION: Extra portion of the keyboard cable must be put under the palm rest.
3. Install the keyboard support plate and secure it with the following screw.
• M2.5×6B FLAT HEAD screw ×1
4. Turn the keyboard face up and set it in place.
5. Secure the keyboard with the following screws.
• M2.5×4B FLAT HEAD screw ×2
6. Install the keyboard holder and press to secure the latches.

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
