Toshiba TECRA A9 Series Maintenance Manual

Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-9
C.5 CN2110 PC card interface connector (70-pin)
Table C-5 PC card interface connector (70-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 GND - 2 ACAD00-PYP I/O
3 ACAD01-PYP I/O 4 ACAD03-PYP I/O
5 ACAD05-PYP I/O 6 ACAD07-PYP I/O
7 ACCBE0-PYN I/O 8 ACAD09-PYP I/O
9 ACAD11-PYP I/O 10 ACAD12-PYP I/O
11 ACAD14-PYP I/O 12 ACCBE1-PYN I/O
13 ACPAR-PYP I/O 14 ACPERR-PYN I/O
15 ACGNT-PYN I/O 16 ACINT-PYN
17 MCVCCA-PYV I 18 MCVPPA-PYV I
19 ACCLK-PYP 20 ACIRDY-PYN I/O
21 ACCBE2-PYN I/O 22 ACAD18-PYP I/O
23 ACAD20-PYP I/O 24 ACAD21-PYP I/O
25 ACAD22-PYP I/O 26 ACAD23-PYP I/O
27 ACAD24-PYP I/O 28 ACAD25-PYP I/O
29 ACAD26-PYP I/O 30 ACAD27-PYP I/O
31 ACAD29-PYP I/O 32 ACD02-PYP I/O
33 ACCLKR-PYN I/O 34 GND -
35 GND - 36 ACCD1-P3N O
37 ACAD02-PYP I/O 38 ACAD04-PYP I/O
39 ACAD06-PYP I/O 40 ACD14-PYP I/O
41 ACAD08-PYP I/O 42 ACAD10-PYP I/O
43 ACVS1-P3P I/O 44 ACAD13-PYP I/O
45 ACAD15-PYP I/O 46 ACAD16-PYP I/O
47 ACA18-PYP 48 ACLOCK-PYN I/O
49 ACSTOP-PYN I/O 50 ACDEVS-PYN I/O
51 MCVCCA-PYV I 52 MCVPPA-PYV I
53 ACTRDY-PYN I/O 54 ACFRAM-PYN I/O
55 ACAD17-PYP I/O 56 ACAD19-PYP I/O
57 ACVS2-P3P I/O 58 ACRST-PYN
59 ACSERR-PYN 60 ACREQ-PYN
61 ACCBE3-PYN I/O 62 ACAUDI-PYP
63 ACSTSC-PYP 64 ACAD28-PYP I/O
65 ACAD30-PYP I/O 66 ACAD31-PYP I/O
67 ACCD2-P3N O 68 GND -
69 GND - 70 GND -

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
