Toshiba TECRA A9 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-22 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
C.24 J6310 Headphone connector (6-pin)
Table C-24 Headphone connector (6-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 A-GND - 2 HEADL-PXP O
3 HEADR-PXP O 4 DETCTA-P4N O
5 A-GND - 6 NC -
C.25 CN8771 FAN interface connector (4-pin)
Table C-25 FAN interface connector (4-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 P5V - 2 FANGO-E3P I
3 GND -
4
FPWMO-S3P O
C.26 CN8800 DC-IN connector (4-pin)
Table C-26 DC-IN connector (4-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 ADPDC - 2 ADPDC -
3 GND - 4 GND -
C.27 CN8810 Main Battery connector (10-pin)
Table C-27 Main Battery connector (10-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 (Q8811-1) - 2 BTMP1 I
3 (Q8811-4) - 4 M5V I
5 PSCL-S5P I/O 6 PSDA-S5P I/O
7 GND - 8 DBT1OV-S5N I
9 GND - 10 GND -
