4 Replacement Procedures 4.8 Bluetooth module
4-24 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)
Installing the Bluetooth module
To install the Bluetooth module, follow the steps below and refer to Figure 4-12.
1. Connect the Bluetooth cable to the connector CN4400 on the system board.
2. Stick a new insulator that prevents a waterdrop from entering the computer.
NOTE: Do not reuse the removed insulator.
3. Connect the Bluetooth cable to the connector on the Bluetooth module.
4. Install the Bluetooth module to the slot until the hook latches.
5. Connect the Bluetooth antenna cable to the connector on the Bluetooth module.
