Toshiba TECRA A9 Series Maintenance Manual

4.28 Hinge 4 Replacement Procedures
4.28 Hinge
Removing the Hinge
To remove the hinge, follow the steps below and refer to Figure 4-50 and 4-51.
1. Remove the following screws.
• M2.5×4B FLAT HEAD screw ×2
• M2.5×6C Tapping screw ×4
2. Stand the LCD mask and remove it.
CAUTION: When standing the LCD mask, be careful not to hold the top portion.
M2.5×6C Tapping
M2.5×4B FLAT HEAD
M2.5×6C Tapping
LCD mask
M2.5×6C Tapping
M2.5×4B FLAT HEAD
Figure 4-50 Removing the LCD mask
TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633) [CONFIDENTIAL] 4-89

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
