Toshiba TECRA A9 Series Maintenance Manual

Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-11
C.7 CN2300 Docking interface connector (133-pin)
Table C-7 Docking interface connector (133-pin) (1/3)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DCOUT
I
2 DCOUT
I
3 DOCDT1-S3N
O
4 GND
-
5 NC
-
6 NC
-
7 NC
-
8 NC
-
9 GND
-
10 ZUSBDC-E3P
I/O
11 ZUSBDC-E3N
I/O
12 GND
-
13 GND
-
14 NC
-
15 NC
-
16 GND
-
17 NC
-
18 NC
-
19 GND
-
20 GND
-
21 GND
-
22 ZNDTX2-P3P
I
23 ZNDTX2-P3N
I
24 GND
-
25 ZNDTX1-P3P
I
26 ZNDTX1-P3N
I
27 GND
-
28 DVIDET-P3N
O
29 - - 30 - -
31 - - 32 - -
33 - - 34 - -
35 - - 36 DCOUT
I
37 DCOUT
I
38 NC
-
39 NC
-
40 NC
-
41 NC
-
42 GND
-
43 NC
-
44 GND
-
45 DPCONF-S5P
O
46 GND
-
47 GND
-
48 XNDCK0-P3N
I
49 XNDCK0-P3P
I
50 GND
-
51 NC
-
52 NC
-
53 GND
-
54 ZNDTX0-P3P
I
55 ZNDTX0-P3N
I
56 GND
-
57 GND
-
58 GND
-
59 GND
-
60 NVBSCL-P3P
I/O
61 NVBSDA-P3P
I/O
62 LAN-E3V
I
63 LINK-E3N
O
64 - -
65 - - 66 - -
67 ZBIDDP-EXP 68 ZBIDDN-EXN
