Toshiba TECRA A9 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-12 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
Table C-7 Docking interface connector (133-pin) (2/3)
Pin No. Signal Name I/O Pin No. Signal Name I/O
69 ZBIDCN-EXN 70 ZBIDCP-EXP
71 DCOUT I 72 DCOUT I
73 PWRSW-S3N O 74 DDCON-P5P I
75 NC - 76 NC
-
77 GND
-
78 GND
-
79 GND
-
80 NC
-
81 GND
-
82 GND
-
83 GND
-
84 GND
-
85 NC
-
86 GND
-
87 NC
-
88 GND -
89 GND
-
90 DBLUE-PXP I
91 GND
-
92 DRED-PXP I
93 GND
-
94 GND
95 DCRTSD-P3P I/O 96 DCRTSC-P3P I/O
97 GND - 98 ACT-E3N O
99 - - 100 - -
101 - - 102 ZBIDBN-EXN I
103 ZBIDBP-EXP I 104 ZBIDAN-EXN O
105 ZBIDAP-EXP O 106 DCOUT I
107 DCOUT I 108 EJCTRQ-S3N O
109 M5V I 110 NC -
111 NC - 112 GND -
113 DHSYNC-P3P I/O 114 DVSYNC-P3P I/O
115 GND
-
116 GND
-
117 NC
-
118 NC
-
119 GND
-
120 GND
-
121 GND
-
122 NC
-
123 NC
-
124 GND -
125 GND
-
126 DGREEN-PXP I
127 GND
-
128 GND -
129 GND - 130 PSCL-S5P I/O
131 PSDA-S5P I/O 132 GND -
133 DOCDT2-S3N O
