Toshiba TECRA A9 Series Maintenance Manual

Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-1
Appendix C
Appendix C Pin Assignments
System board (FHMLS*)
C.1 CN1400 SO-DIMM0 connector (200-pin)
Table C-1 SO-DIMM0 connector (200-pin) (1/3)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 MRVREF-B0V I 2 GND -
3 GND - 4 ADQ04-B1P I/O
5 ADQ00-B1P I/O 6 ADQ06-B1P I/O
7 ADQ05-B1P I/O 8 GND -
9 GND - 10 ADM0-B1P I/O
11 ADQS0-B1N I/O 12 GND -
13 ADQS0-B1P I/O 14 ADQ07-B1P I/O
15 GND - 16 ADQ01-B1P I/O
17 ADQ03-B1P I/O 18 GND -
19 ADQ02-B1P I/O 20 ADQ08-B1P I/O
21 GND - 22 ADQ12-B1P I/O
23 ADQ14-B1P I/O 24 GND -
25 ADQ13-B1P I/O 26 ADM1-B1P I
27 GND - 28 GND -
29 ADQS1-B1N I/O 30 XMCK0-B1P I
31 ADQS1-B1P I/O 32 XMCK0-B1N I
33 GND - 34 GND -
35 ADQ15-B1P I/O 36 ADQ09-B1P I/O
37 ADQ11-B1P I/O 38 ADQ10-B1P I/O
39 GND - 40 GND -
41 GND - 42 GND -
43 ADQ21-B1P I/O 44 ADQ16-B1P I/O
45 ADQ20-B1P I/O 46 ADQ17-B1P I/O
47 GND - 48 GND -
49 ADQS2-B1N I/O 50 TSDIMA-P3N
（NC）
-
51 ADQS2-B1P I/O 52 ADM2-B1P I
53 GND - 54 GND -
55 ADQ18-B1P I/O 56 ADQ19-B1P I/O
57 ADQ23-B1P I/O 58 ADQ22-B1P I/O
59 GND - 60 GND -
61 ADQ28-B1P I/O 62 ADQ25-B1P I/O
