3 Tests and Diagnostics 3.28LAN/Modem/Bluetooth/IEEE1394 Test Program
Subtest01 (i82562 + ICHx)
This subtest checks the operation of mini-PCI I/F by the loopback test in the
chip.
The following message will appear:
[LAN transmit & receive test !]
COMPLETED Repeat count = 00000
Error count = 00000
LOOPBACK TEST
100Mbps Auto-negotiation TxRx Test
Destination Address = xxxxxxxxxxxx
Source Address = xxxxxxxxxxxx
** 100Base-TX Full-Duplex **
< TRANSMIT >
< RECEIVE >
NOTE: The menu displayed by your computer may be slightly different from the one
shown above.
If a defective is found, NG message will appear in the display.
3-74 [CONFIDENTIAL] TECRA A9(S5/P5/S200) Maintenance Manual (960-631)
