3 Tests and Diagnostics 3.28 LAN/Modem/Bluetooth/IEEE1394 Test Program
5. Select “Diagnostics” tab and click “Run”.
6. Check the “Log” to confirm the test result.
BT address of test computer
BT address of responder
device
7. When the BT (Bluetooth) address of the responder device appears, the Bluetooth card
and antenna connection are OK.
If the BT address of the responder device does not appear, check the Bluetooth card
condition and antenna cable connection to the Bluetooth card by disassembling the
computer following the steps described in Chapter 4, Replacement Procedures.
3-78 [CONFIDENTIAL] TECRA A9(S5/P5/S200) Maintenance Manual (960-631)
