4 Replacement Procedures 4.10 Fan hood
4-28 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)
Installing the Fan hood
To install the fan hood, follow the steps below and refer to Figure 4-15.
1. Install the fan hood into the slot.
2. Stick a new insulator that prevents a waterdrop from entering the computer.
NOTE: Do not reuse the removed insulator.
