Toshiba TECRA A9 Series Maintenance Manual

4 Replacement Procedures 4.11 Wireless LAN card
4-32 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)
Installing the Wireless LAN card
To install the wireless LAN card, follow the steps below and refer to Figure 4-16 to 4-18.
CAUTION: Be sure to switch the computer off before installing the wireless LAN card.
Otherwise, the computer or the wireless LAN card may be damaged.
1. Pass the Bluetooth antenna cable through the hole of the cover assembly and
arrange it into the slot of the cover assembly in place.
2. Pass the wireless LAN antenna cables through the holes of the cover assembly and
arrange them in place.
3. Stick a new insulator that prevents a waterdrop from entering the computer in place.
NOTE: Do not reuse the removed insulator.
4. Insert the wireless LAN card to the connector on the system board slantwise and
press it to connect firmly.
5. Connect the wireless LAN antenna cables to the connectors on the wireless LAN
card.
NOTE: In the wireless LAN card that has three connectors, connect the white cable to 1,
black to 2 and gray to 3 marked on the wireless LAN card.
6. Secure the wireless LAN card with the following screws.
• M2×4B BIND ×2
7. Stick a new insulator that prevents a waterdrop from entering the computer.
NOTE: Do not reuse the removed insulator.

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
