4.26 Wireless LAN antenna/Bluetooth antenna 4 Replacement Procedures
CAUTION: (Upper left)
Peel off the separators of the Wireless LAN antennas (white cable and gray
cable) and stick the wireless LAN antenna (white cable and gray cable) to
the display rear cover.
Wireless LAN antenna (gray cable)
Wireless LAN antenna (white cable)
TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633) [CONFIDENTIAL] 4-83
