4.28 Hinge 4 Replacement Procedures
TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633) [CONFIDENTIAL] 4-91
Installing the Hinge
To install the hinge, follow the steps below and refer to Figure 4-50 and 4-51.
1. Install the left hinge while engaging the hook and secure it with the following screw.
• M2.5×6C Tapping screw ×1
2. Install the right hinge while engaging two hooks and secure it with the following
screws.
• M2.5×6C Tapping screw ×1
• M2.5×4B FLAT HEAD screw ×1
3. Install the LCD mask and lay it down.
CAUTION: When laying the LCD mask down, be careful not to hold the top portion.
4. Secure the LCD mask with the following screws.
• M2.5×4B FLAT HEAD screw ×2
• M2.5×6C Tapping screw ×4
To Next Page
