Toshiba TECRA A9 Series Maintenance Manual

Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-3
Table C-1 SO-DIMM0 connector (200-pin) (3/3)
Pin No. Signal Name I/O Pin No. Signal Name I/O
133 GND - 134 ADQ37-B1P I/O
135 ADQ38-B1P I/O 136 ADQ34-B1P I/O
137 ADQ39-B1P I/O 138 GND -
139 GND - 140 ADQ41-B1P I/O
141 ADQ44-B1P I/O 142 ADQ45-B1P I/O
143 ADQ40-B1P I/O 144 GND -
145 GND - 146 ADQS5-B1N I/O
147 ADM5-B1P I 148 ADQS5-B1P I/O
149 GND - 150 GND -
151 ADQ42-B1P I/O 152 ADQ47-B1P I/O
153 ADQ46-B1P I/O 154 ADQ43-B1P I/O
155 GND - 156 GND -
157 ADQ49-B1P I/O 158 ADQ48-B1P I/O
159 ADQ52-B1P I/O 160 ADQ53-B1P I/O
161 GND - 162 GND -
163 N.C. - 164 XMCK1-B1P I
165 GND - 166 XMCK1-B1N I
167 ADQS6-B1N I/O 168 GND -
169 ADQS6-B1P I/O 170 ADM6-B1P I
171 GND - 172 GND -
173 ADQ51-B1P I/O 174 ADQ55-B1P I/O
175 ADQ50-B1P I/O 176 ADQ54-B1P I/O
177 GND - 178 GND -
179 ADQ58-B1P I/O 180 ADQ61-B1P I/O
181 ADQ62-B1P I/O 182 ADQ60-B1P I/O
183 GND - 184 GND -
185 ADM7-B1P I 186 ADQS7-B1N I/O
187 GND - 188 ADQS7-B1P I/O
189 ADQ59-B1P I/O 190 GND -
191 ADQ63-B1P I/O 192 ADQ56-B1P I/O
193 GND - 194 ADQ57-B1P I/O
195 SMBDT1-E3P I/O 196 GND -
197 SMBCK1-E3P I/O 198 GND -
199 M-E3V I 200 GND I
1T GND - 2T GND -
3T GND - 4T GND -

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
