1.8 Power Supply 1 Hardware Overview
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] 1-25
Table 1-6 Power supply output rating (3/4)
Use Voltage (V) Name
SIM Card 3.3 UIMPWR-E3V
1.5 1R5-P1V
Robson
3.3 P3V
SPI 3.3 LAN-E3V
MDC 3.3 E3V
EC/KBC 3.3 S3V
Touch Pad 5 SP-P5V
LED 5 M5V
3.3 E3V
TPM
3.3 P3V
Accelerometer 3.3 S3V
3.3 FS-E3V
Finger Sens.
5 FS-E5V
Finger Sens PS. 3.3 E3V
Super I/O 3.3 P3V
RS232C Driver 3.3 P3V
1.05 LN1R0- E1V
1.8 LN1R8- E1V
LAN
3.3 LNP -E3V
LAN PS 3.3 E3V
Bluetooth 3.3 BT-P3V
Bluetooth PS 5 P5V
5 USB0PS-E5V
USB
5 USB1PS-E5V
USB PS 5 E5V
