Toshiba TECRA A9 Series Maintenance Manual

2.3 Power Supply Troubleshooting 2 Troubleshooting Procedures
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] 2-9
 1R5-C1V output (P62)
Error code Meaning
60h 1R5-C1V voltage is over 2.15V when the computer is powered on/off.
61h 1R5-C1V voltage is 1.275V or less when the computer is powered on.
62h 1R5-C1V voltage is 1.275V or less when the computer is booting up
63h 1R5-C1V voltage is 1.275V or less when the computer is suspended.
64h 1R5-C1V voltage is not Normal when the CV support is in Shutdown(s)
state.
65h 1R5-C1V voltage is 1.275V or less when the CV support is booting up
 PPV output (P63:MUX- CH0)
Error code Meaning
70h PPV voltage is over 1.80V when the computer is powered on/off.
71h PPV voltage is 0.56V or less when the computer is powered on.
72h PPV voltage is 0.56V or less when the computer is booting up
73h PPV voltage is 0.56V or more when the computer is powered off.
 PGV output (P64:MUX- CH0)
Error code Meaning
80h PGV voltage is over 6.00V when the computer is powered on/off.
81h PGV voltage is 4.50V or less when the computer is powered on.
82h PGV voltage is 4.50V or less when the computer is booting up
83h PGV voltage is 4.50 or more when the computer is powered off.
84h PGV voltage is 4.50V or less when the computer is suspended.
 PTV output (P65:MUX- CH0)
Error code Meaning
90h PTV voltage is over 1.26V when the computer is powered on/off.
91h PTV voltage is 0.89V or less when the computer is powered on.
92h PTV voltage is 0.89V or less when the computer is booting up
93h PTV voltage is 0.89 or more when the computer is powered off.
94h PTV voltage is 0.89V or less when the computer is suspended.
