Toshiba Tecra M10 - Removing the SIM Card

4.3 SIM card 4 Replacement Procedures
4.3 SIM card
Removing the SIM card
To remove the SIM card, follow the steps below and refer to Figure 4-2 and 4-3.
1. Slide the SIM card release latch in the direction as shown in the figure below.
2. Turn up the SIM card holder in the direction as shown in the figure below.
SIM card release latch
SIM card holder
Figure 4-2 Removing the SIM card (1)
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] 4-13
