Appendix C Pin Assignments Appendices
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] C-19
C.16 CN6150 Speaker interface connector (4-pin)
Table C-16 Speaker interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 SPOTL-PXN 2 SPOTL-PXP
3
SPOTR-PXP
4
SPOTR-PXN
C.17 CN8771 FAN interface connector (4-pin)
Table C-17 FAN interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 E5B 2 FANG0-P3P
3 GND 4
FPWM0-S3P
1T
GND
2T
GND
