Appendix B Board Layout Appendices

B.13 SIM board (FGGSM*) View

(front)

(back)

Figure B-13 SIM board (FGGSM*) layout (front

/back

)

Table B-13 SIM

board

(FGGSM*) connector (

back

)

Number Name

CN9670 System board I/F connector

TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] B-19
