4.32 LCD harness 4 Replacement Procedures

4.32 LCD harness

Removing the LCD harness

To remove the LCD harness, follow the steps below and refer to Figure 4-61 to 4-63.

1. Turn up the insulator and release the LCD harness from the guide.

LCD harness

Insulator

Guide

Figure 4-61 Removing the LCD harness (1)

TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] 4-101
