4 Replacement Procedures 4.35 Fluorescent Lamp

Assembly of outside tape/Cover shield

1. Assembly of Cover shield (S)1.

CAUTION: Pressure or stress should not be given on Source PCB. Usage of gloves with

anti-electric discharge coating is recommended to eliminate possible

damage on circuits occurred by ESD.

2. Assembly of Tape Adhesive2 used for Top case fixing.

CAUTION: Pressure or stress should not be given on Top case during this process.

Figure 4-75 Replacing 14.1-inch LG fluorescent lamp (WXGA) (8)

4-118 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
