Toshiba Tecra M10 - CN3420 Serial Interface Connector (9-Pin); CN9620 System Board Interface Connector (12-Pin)

Appendices Appendix C Pin Assignments
C-34 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
Serial board (FG6SR*/FGGSR*)
C.37 CN3420 Serial interface connector (9-pin)
Table C-37 Serial interface connector (9-pin)
Pin No. Signal Name Pin No. Signal Name
1
DCD-PYP
2
RXD-PYN
3 TXD-PYN 4 DTR-PYP
5 GND 6 DSR-PYP
7 RTS-PYP 8 CTS-PYP
9 RING-PYP
1T GND 2T GND
C.38 CN9620 System board interface connector (12-pin)
Table C-38 System board interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1
RXD-P3P
2
TXD-P3P
3 DSR-P3N 4 RTS-P3N
5 GND 6 CTS-P3N
7 DTR-P3N 8 RING-P3N
9 DCD-P3N 10 P3V
11 KRSSD-P3N 12 GND
1T GND 2T GND
