4.23 PC card unit 4 Replacement Procedures

TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] 4-71

Installing the PC card unit

To install the PC card unit, follow the steps below and refer to Figure 4-45.

1. Set the PC card unit while engaging the latches and secure it with the following

screws.

• M2.0×3C Tapping screw ×2

• M2.0×8C Tapping screw ×2
