4 Replacement Procedures 4.33 LCD mask
4-106 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
Installing the LCD mask
To install the LCD mask, follow the steps below and refer to Figure 4-64 to 4-65.
1. Set the LCD mask to the hinge standing.
2. Lay the LCD mask down and secure it with the following screws.
CAUTION: When laying the LCD mask down, hold the LCD mask with the hinge and lay
them down carefully.
• M2.5×4B FLAT HEAD screw ×2
• M2.5×6C Tapping screw ×2
