4 Replacement Procedures 4.20 System board

4. Disconnect the DC-IN harness and HDD harness from the connector CN8800 and

CN1900 on the back of the system board.

CN8800

CN1900

HDD harness

DC-IN harness

Figure 4-37 Removing the DC-IN harness/HDD harness

4-60 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
