Toshiba Tecra M10 - CN8800 DC-IN Connector (4-Pin); CN8810 Battery Connector (10-Pin)

Appendices Appendix C Pin Assignments
C-20 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
C.18 CN8800 DC-IN connector (4-pin)
Table C-18 DC-IN connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 ADPDC 15V 2 ADPDC 15V
3
GND
4
GND
C.19 CN8810 Battery connector (10-pin)
Table C-19 Battery connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 Q8811-1pin 2 BTMP1
3 Q8811-4pin 4
M5V
5
PSCL-S5P
6
PSDA-S5P
7
GND
8
DBT1OV-S5N
9
GND
10
GND
