4.15 Speaker 4 Replacement Procedures
4.15 Speaker
Removing the Speaker
To remove the speaker, follow the steps below and refer to Figure 4-25 to 4-27.
1. Disconnect the speaker harness from the connector CN6150 on the system board.
CN6150
Speaker harness
Figure 4-25 Removing the speaker (1)
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] 4-43
