Toshiba Tecra M10 - Serial Board (FG6 SR*;FGGSR*) View

To Next Page

To Previous Page

Appendix B Board Layout Appendices

B.9 Serial board (FG6SR*/FGGSR*) View

(front)

(back)

Figure B-9Serial board (FG6SR*/FGGSR*) layout (front/back)

Table B-9

Serial board (FG6SR*/FGGSR*) connector (

back

)

Number Name

CN3420

Serial I/F connector

CN9620

System board I/F connector

TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] B-15
