Appendix C Pin Assignments Appendices
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] C-35
Sound board (FG6SN*/FGGSN*/FGASN*)
C.39 CN6050 Int-Mic interface connector (2-pin)
Table C-39 Int-Mic interface connector (2-pin)
Pin No. Signal Name Pin No. Signal Name
1 IMICIN-PXP 2 GND
C.40 CN9300 RTCVCC interface connector (3-pin)
Table C-40 RTCVCC interface connector (3-pin)
Pin No. Signal Name Pin No. Signal Name
1 RTC-R3V 2 NC
3 GND
1T GND 2T GND
