4 Replacement Procedures 4.35 Fluorescent Lamp

Assembly of Source PCB

1. Assembly of Source PCB1.

CAUTION: Stress should not be given on COF.

Figure 4-73 Replacing 14.4-inch LG fluorescent lamp (WXGA) (6)

4-116 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
