Toshiba Tecra M10 - CN9500 FGGSW* Board Interface Connector (8-Pin); CN9510 RGB Interface Connector (12-Pin; Table

Appendix C Pin Assignments Appendices
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] C-21
C.20 CN9500 FGGSW* board interface connector (8-pin)
Table C-20 FGGSW* board interface connector (8-pin)
Pin No. Signal Name Pin No. Signal Name
1 PWRSW-S3N 2 GPBTNA-S3N
3 GPBTNB-S3N 4
PNLOFF-S3N
5
NC
6
S3V
7
SERDBG-P3N
8
GND
1T
GND
2T
GND
C.21 CN9510 RGB interface connector (12-pin)
Table C-21 RGB interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 CRTSDA-P5P
3 CRTSCL-P5P 4
GND
5
MVSYNC-P3P
6
MHSYNC-P3P
7
GND
8
MBLUE-PXP
9
GND
10
MGREEN-PXP
11
GND
12
MRED-PXP
