Toshiba Tecra M10 - Sound Board (FG6 SN*;FGGSN*;FGASN*) View

To Next Page

To Previous Page

Appendices Appendix B Board Layout

B.10 Sound board (FG6SN*/FGGSN*/FGASN*) View

(front)

(back)

Figure B-10 Sound

board

(FG6SN*/FGGSN*) layout (front/back)

Table B-10

Sound

board

(FG6SN*/FGGSN*) connector (back)

Number Name

CN6050 Int-Mic I/F connector

CN9300 RTCVCC I/F connector

CN9630 System board I/F connector

J6051 Microphone connector

J6310 Headphone connector

B-16 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
