Chapter 2 Modem installation
16 BMTX-SVN01C-EN
Figure 6. Exploded view of BMTX BCU showing modem installation
parts for a 230 V system
Stand-offs (2)
Modem cover screws (4)
Modem cover
Modem
Spacer
Shield
Main
circuit
board
Frame
