Trane Tracer Summit Hardware And Software Installation

Connecting the main circuit board
BMTX-SVN01C-EN 25
Figure 13. Cable connector and LED display locations
Operator-display connector
24 Vac power connector
Seven-segment
LED display
Ethernet connector
Modem card (optional)
Modem, phone line
connector
