Transportation and erection
Final assembly on site
43
3. Release mounting bolts (3) and adjust the height.
? Is the conveyor on optimal setting?
The standard belt conveyor is delivered with a drawn in endless belt. The
conveyor is delivered with an optimum set up.
However, if you do have to readjust the tension of the belt, please
proceed as described in "Maintenance."
Supports have been fitted.
Mount frame
Complete the following steps:
1. Pre-position the individual sections on the conveyor bed as shown by the
decals.
2. Demount the tail pulley and insert the belt loop (refer to section "Mainte-
nance," "Change the belt").
