Multicast Filtering
Multicast Filtering
Network > Multicast VLAN Settings
1. Log into your switch management page (see “Access your switch management page”
on page 5).
2. Click on Network, click on Multicast VLAN, and click on Multicast VLAN Settings.
3. Review the settings. Click Apply to save the settings.
• Multicast Filter Mode –Select forward or filter multicast traffic on this port.
4. At the bottom of the left hand panel, click Save.
5. Select the Config you would like to save the settings to, then click Save Settings to
Flash.
Note: This step saves all configuration changes to the NV-RAM to ensure that if the
switch is rebooted or power cycled, the configuration changes will still be applied.
Bandwidth Control
Storm Control
Network > Bandwidth Control > Storm Control
This section allows you to configure the DLF (Destination Lookup Failure), broadcast,
and multicast storm settings for each switch port.
1. Log into your switch management page (see “Access your switch management page”
on page 5).
2. Click on Network, click on Bandwidth Control, and click on Storm Control.
3. Review the settings for each port. Click Apply to save the settings.
• DLF (Destination Lookup Failure) – Click the drop-down list and select Enabled
to enable DLF storm control.
• Broadcast – Click the drop-down list and select Enabled to enable broadcast
storm control.
• Multicast – Click the drop-down list and select Enabled to enable multicast
storm control.
• Threshold – Enter the pps (packets per second) threshold.
Note: Modifying settings in the row marked All, will apply the settings to all
ports.
4. At the bottom of the left hand panel, click Save.
5. Select the Config you would like to save the settings to, send click Save Settings to
Flash.
Note: This step saves all configuration changes to the NV-RAM to ensure that if the
switch is rebooted or power cycled, the configuration changes will still be applied.
