TRENDnet User’s Guide
Web Smart Switch Series
5. Select the Config you would like to save the settings to, then click Save Settings to
Flash.
Note: This step saves all configuration changes to the NV-RAM to ensure that if the
switch is rebooted or power cycled, the configuration changes will still be applied.
Scheduling Algorithm
Set the Scheduling Algorithm
QoS > Scheduling Algorithm
1. Log into your switch management page (see “Access your switch management page”
on page 5).
2. Click on QoS and click on Scheduling Algorithm.
3. Review the settings. Click Apply to save the settings.
• Strict Priority - The port transmits all packets out of higher priority queues
before transmitting any from the lower priority queues.
• WRR (Weighted RoundRobin) - The port transmits a set number of packets
from each queue, in a round robin fashion, so that each has a chance to
transmit traffic.
4. At the bottom of the left hand panel, click Save.
5. Select the Config you would like to save the settings to, then click Save Settings to
Flash.
Note: This step saves all configuration changes to the NV-RAM to ensure that if the
switch is rebooted or power cycled, the configuration changes will still be applied.

TRENDnet Web Smart Switch Series Specifications

General

Category	Switch
Ports	8, 16, 24, or 48 ports (depending on model)
Power over Ethernet (PoE)	Available on select models
Switching Capacity	Varies by model (e.g., 16 Gbps)
Forwarding Rate	Varies by model (e.g., 11.9 Mpps)
MAC Address Table	Varies by model (e.g., 8K, 16K)
VLAN Support	Yes (802.1Q)
Quality of Service (QoS)	Yes (IEEE 802.1p)
Management	Web-based
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
