Triconex Trident - Page 118

102 Input/Output Modules
Trident Planning and Installation Guide
Model 2381 Pulse Input Baseplate Simplified Schematic
To
Other
Points
499
Ω
6-Point PI ModulePI Baseplate
To
Spare
Field Power (PS1) –
Field Power (PS2) –
Comparator
Comparator
Comparator
499 Ω
R+
FE
Shield
Field Power (PS1 +)
Field Power (PS2) +
V+
FE
IN+
IN-
1
6
1
6
1
6
3
4
4
5
4
3
2
2
1
1
1
2
3
Blown
Fuse
Indicator
J29
J23
J24
