50 Input/Output Modules
Trident Planning and Installation Guide
Common Specifications
Wiring Terminals
Logic Power
Feature Specification
Compression terminals Compatible with 24 to 12 (0.2 mm
2
to 3.3 mm
2
)
AWG wiring
Feature Specification
Nominal input voltage 24 V DC
Voltage range 24 V DC –15% or +20% + 5% AC ripple
(19.2 to 30 V DC)
Logic power <3 W
Absolute maximum input voltage 33 V DC
Absolute maximum reverse input
voltage
–0.6 V DC
Input power interruption time
from nominal
1 ms maximum
Power interruption interval 1 sec minimum
Reverse current isolation input to
input
500 µA maximum
Inrush current per input 2.4 A maximum
Short circuit current limit per input 2.4 A maximum
Functional-earth-to-logic-ground
isolation
0 V, no isolation
Protective-to-functional-earth
isolation
500 V DC, minimum
