Trident Planning and Installation Guide
CHAPTER 4
Installation and Maintenance
This chapter provides guidelines for the person responsible for installing and
maintaining a Trident controller.
Topics include:
“Guidelines” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
“Installation Procedures” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
“Effective Grounding Methods” . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
“Connecting to a TriStation PC” . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
“Connecting to Serial Ports on the MP” . . . . . . . . . . . . . . . . . . . . . 161
“Connecting to Serial Ports on the CM” . . . . . . . . . . . . . . . . . . . . . 162
“Configuring Output Voter Diagnostics” . . . . . . . . . . . . . . . . . . . . 163
“Controller Verification” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
“Performing Routine Maintenance” . . . . . . . . . . . . . . . . . . . . . . . . 165
!
CAUTION
The Trident controller can be repaired while operating. However, the integrity of
the controller can only be assured if the operator follows maintenance procedures
correctly. If the operator is in doubt about the procedures, he or she should take
whatever steps are necessary to ensure the safety of the plant and personnel, then
call Triconex for assistance in implementing the maintenance procedures.
