Triconex Trident - DI Field Power Indicator; DI Point Indicators

Digital Input Module Indicators 185
Chapter 5 Fault and Alarm Indicators
DI Field Power Indicator
The DI field power indicator is lit when a field power problem has occurred.
DI Point Indicators
The DI point indicators identify whether the point is energized or not energized.
Field
Power
Description Action
Yellow
steady
Field power from one or more
of the redundant sources is
missing.
To isolate the missing power source, use
the TriStation Diagnostic Panel.
Correct the problem in the field circuit.
If these steps do not solve the problem,
replace the module.
Point (1-32) Description
Green steady Field circuit is energized.
No light Field circuit is not energized.
