Typical Weights
Component Weight in Pounds Weight in Kilograms
Analog Input Module 3.0 1.4
Analog Input Baseplate 2.4 1.1
Analog Output Module 3.1 1.4
Analog Output Baseplate 2.1 1.0
Communication Module 3.3 1.5
Communication Baseplate 2.8 1.3
Digital Input Baseplate 2.4 1.1
Digital Input Module 3.0 1.3
Digital Output Baseplate 2.1 1.0
Digital Output Module 3.2 1.4
Main Processor Baseplate 2.7 1.2
Main Processor Module 3.4 1.5
Pulse Input Module 3.0 1.4
Pulse Input Baseplate 2.8 1.3
Relay Output Baseplate 2.3 1.0
Solid-State Relay Output Module 2.9 1.3
I⁄O Extender Module 0.4 0.2
