Triconex Trident - Chapter 5 Fault and Alarm Indicators; CHAPTER 5 Fault and Alarm Indicators

Trident Planning and Installation Guide
CHAPTER 5
Fault and Alarm Indicators
This chapter describes indicators that identify the state of each module.
Topics include:
“Overview” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
“Main Processor Indicators” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
“Communication Module Indicators” . . . . . . . . . . . . . . . . . . . . . . . 174
“Analog Input Module Indicators” . . . . . . . . . . . . . . . . . . . . . . . . . 177
“Analog Output Module Indicators” . . . . . . . . . . . . . . . . . . . . . . . . 180
“Digital Input Module Indicators” . . . . . . . . . . . . . . . . . . . . . . . . . 183
“Digital Output Module Indicators” . . . . . . . . . . . . . . . . . . . . . . . . 186
“Pulse Input Module Indicators” . . . . . . . . . . . . . . . . . . . . . . . . . . 189
“Solid-State Relay Output Module Indicators” . . . . . . . . . . . . . . . 192
“Replacing Modules” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
!
CAUTION
The Trident controller can be repaired while operating. However, the integrity of
the controller can only be assured if the operator follows repair procedures
correctly. If in doubt about the procedures, the operator should take whatever steps
are necessary to ensure the safety of the plant and personnel, then call Triconex for
assistance in implementing the repair procedures.
