Triconex Trident - Page 123

Input/Output Modules 107
Chapter 3 System Description
PI Baseplate Terminal Block Pin-Outs
Configuration
J23/J26 Signal Point 1 Point 2 Point 3 Point 4 Point 5 Point 6
V+ 1 6 12 17 22 28
R+ 2 7 13182329
FE 3 8 14 19 24 30
IN1– 4 9 15202531
FE 5 1016212632
Sensor
J24/J25 Signal Point 1 Point 2 Point 3 Point 4 Point 5 Point 6
V+ 1 7 13 17 23 29
IN+ 2 8 14182430
IN– 3 9 15192531
Shield 4 1016202632
Resistor
J29/J30 Signal Point 1 Point 2 Point 3 Point 4 Point 5 Point 6
V+ 1 5 9 131722
IN+ 2 6 10141823
IN+ 3 7 11151924
IN– 4 8 12 16 20 25
