Input/Output Modules 63
Chapter 3 System Description
The following table gives the temperature and output ranges for available signal
conditioning modules.
Note Signal conditioners must be ordered separately and are available from
Triconex or directly from Analog Devices.
For availability of signal conditioning modules of other types or with different
input ranges, contact your regional customer center.
Description
1
1. For detailed specifications, see the Analog Devices catalog, Signal Conditioning and Data
Acquisition Solutions.
Part Number Input Range Output Range
Non-Isolated, Process
Current Input Module
1600048-220
(7B32NI)
4 mA to 20 mA 0.4 V to 2 V
Isolated, Linearized,
RTD Input,100 Ω
Platinum, 2- or 3-Wire,
α = 0.00385
1600048-030
(7B34)
0° C to 200° C
(32° F to 392° F)
0.4 V to 2 V
1600048-040
(7B34)
0° C to 600° C
(32° F to 1112° F)
0.4 V to 2 V
Isolated, Linearized,
Type J, Thermocouple
Input Module
1600048-110
(7B47)
0° C to 760° C
(32° F to 1400° F)
0.4 V to 2 V
Isolated, Linearized,
Type K, Thermocouple
Input Module
1600048-120
(7B47)
0° C to 1300° C
(32° F to 2372° F)
0.4 V to 2 V
Isolated, Linearized,
Type T, Thermocouple
Input Module
1600048-130
(7B47)
0° C to 400° C
(32° F to 752° F)
0.4 V to 2 V
Isolated, Linearized,
Type E, Thermocouple
Input Module
1600048-040
(7B47)
0° C to 900° C
(32° F to 1652° F)
0.4 V to 2 V
Shorting Plug
1600048-300
(7BDS)
Not applicable 0.0 V
