GENERAL INFORMATION
91
▼ Align the seat lock peg to the lock
and press down, engaging the seat
lock. An audible click can be heard
when the seat is fully engaged in its
lock.
ckun
1
3
5
4
2
1. Seat
2. Seat lock peg
3. Seat lock
4. Seat tongue
5. Seat tongue locating position
WARNING
To prevent detachment of the seat
during riding, after fitting always
grasp the seat and pull firmly
upwards.
If the seat is not correctly secured in
the lock, it will detach from the lock.
A loose or detached seat may lead to
loss of motorcycle control which could
result in serious injury or death.
▼ Grasp the seat and pull firmly
upwards to ensure that it is securely
retained.
TigerSport
Seat
▼ Align the two locating slots at the
front of the seat with the locating
tangs on the frame.
▼ Engage the seat tongue with the
seat tongue locating position on the
fuel tank rear panel.
B01854
1
3
2
1. Seat
2. Locating slots
3. Seat tongue
B01850_1
1
2
1. Seat tongue locating position
2. Locating tangs
